Hardware Coating Production Line for Durable Metal Surface Finishing
Hardware coating production line is designed for continuous surface finishing of metal hardware, brackets, fasteners, panels, frames, housings, and other industrial metal parts. It helps manufacturers improve coating adhesion, corrosion resistance, appearance consistency, production rhythm, and first-pass coating quality.
Product Description
KYD hardware coating production line is developed for manufacturers that need customized pretreatment, drying, powder coating, spray painting, curing, cooling, conveying, powder recovery, inspection, and loading or unloading systems for hardware parts. The equipment can be configured as a manual, semi-automatic, or fully automatic production line according to the customer’s workpiece size, coating process, quality target, output requirement, workshop layout, and environmental protection needs.
Each system is designed according to hardware material, part geometry, hanging or fixture method, surface condition, pretreatment process, coating material, curing temperature, conveyor speed, production capacity, safety requirements, and destination country standards. KYD provides engineering review, process layout planning, mechanical design, electrical control, manufacturing, assembly, debugging, and export support for hardware coating production projects.
Main Features
- Customized coating process for hardware loading, degreasing, rinsing, pretreatment, drying, powder spraying or wet spraying, curing, cooling, and unloading.
- Integrated pretreatment tunnel, drying oven, coating booth, powder recovery system, curing oven, conveyor, inspection station, and control cabinet.
- PLC control, HMI operation, conveyor speed adjustment, oven temperature control, spray system interface, alarm system, and production status display are available.
- Designed for stable coating thickness, improved adhesion, reduced manual spraying variation, cleaner workshop operation, and repeatable batch finishing quality.
- Line layout, conveyor type, booth size, oven length, heating method, recovery system, hanging fixture, automation level, and voltage can be customized.
Quick Configuration
- Equipment typeHardware coating line
- WorkpieceMetal hardware parts
- Line modeManual / semi-auto / auto
- ControlPLC / HMI / conveyor
- CustomizationBooth, oven, conveyor
Technical parameters
Hardware Coating Production Line Specifications
The following parameters are for reference. KYD can customize the hardware coating production line according to part size, part weight, coating process, pretreatment requirement, target output, workshop layout, automation level, and export requirements.
| Applicable workpiece | Hardware parts, brackets, fasteners, hinges, handles, metal panels, frames, shells, racks, cabinet parts, appliance parts, and custom metal components |
| System scope | Loading, pretreatment, degreasing, rinsing, drying, powder coating or spray painting, powder recovery, curing, cooling, inspection, unloading, and transfer |
| Production capacity | Designed according to part size, hanging density, conveyor speed, coating cycle, curing time, shift output, and automation level |
| Main modules | Loading station, pretreatment tunnel, dry-off oven, coating booth, spray gun system, powder recovery unit, curing oven, cooling section, conveyor line, control cabinet |
| Control system | PLC control, HMI interface, conveyor speed control, oven temperature control, spray system interface, motor control, alarm system, optional data collection |
| Safety design | Guarding, emergency stop, interlock, ventilation interface, grounding, warning light, fire protection interface, and customized protection layout |
| Power supply | 380V / 50Hz standard, voltage can be customized for export projects |
| Optional modules | Automatic spray guns, manual touch-up booth, robot spraying, powder reclaim system, wastewater treatment, exhaust treatment, barcode tracking, MES connection, and remote support interface |
