Winding Machine for Controlled Wire, Coil, and Material Winding
Winding machines are designed to wind wire, cable, fiber, tape, or other continuous materials onto a spool, coil body, bobbin, or fixture with controlled speed and laying movement. They help improve winding consistency, reduce manual labor, and support repeatable coil or roll production.
Product Description
KYD winding machine is developed for manufacturers that need customized winding spindles, wire guiding units, tension control, traverse mechanisms, fixtures, counting systems, cutting or clamping options, and automated loading or unloading interfaces. The equipment can support coil winding, material winding, wire laying, tension adjustment, turn counting, transfer, and downstream handling according to the customer’s process route.
Each system is designed according to the wire or material type, diameter, winding shape, bobbin size, number of turns, tension requirement, production capacity, workshop layout, safety requirements, and destination country standards. KYD provides engineering review, fixture planning, mechanical design, electrical control, manufacturing, assembly, debugging, and export support for winding machine projects.
Main Features
- Customized winding fixture and spindle layout based on coil shape, bobbin size, material diameter, tension range, and output target.
- Controlled rotation, traverse movement, turn counting, wire guiding, tension control, and optional cutting or clamping.
- Servo or motor drive, guide nozzle, sensors, PLC control, HMI operation, and safety protection are available.
- Designed for stable winding pitch, reduced manual variation, easier recipe adjustment, quick fixture change, and consistent product quality.
- Voltage, spindle quantity, winding speed, traverse stroke, tension range, and automation level can be customized.
Quick Configuration
- Equipment typeWinding machine
- WorkpieceWire / coil / roll material
- Line modeStandalone or integrated
- ControlPLC / HMI / servo control
- CustomizationSpeed, tension, fixture
Technical parameters
Winding Machine Specifications
The following parameters are for reference. KYD can customize the winding machine according to wire type, coil geometry, bobbin size, winding turns, tension requirement, target capacity, and export requirements.
| Applicable workpiece | Wire, cable, fiber, tape, coil bodies, bobbins, spools, and custom continuous materials |
| Process scope | Material feeding, tension adjustment, winding, traverse laying, turn counting, clamping, cutting option, unloading, and transfer |
| Production capacity | Designed according to winding turns, spindle quantity, material diameter, winding speed, and automation level |
| Main modules | Machine frame, winding spindle, guide unit, traverse mechanism, tension device, fixture, sensor system, control cabinet |
| Control system | PLC control, HMI interface, servo or motor control, turn counting, tension feedback, alarm system, optional recipe management |
| Safety design | Guarding, emergency stop, interlock, protective cover, warning light, and customized protection layout |
| Power supply | 380V / 50Hz standard, voltage can be customized for export projects |
| Optional modules | Automatic loading, cutting unit, wire clamping, multi-spindle design, barcode tracking, data collection, and remote support interface |
Application scenarios
Where Winding Machines Are Used
Coil and Bobbin Winding
Used for winding wire or cable onto bobbins, coils, spools, or custom fixtures with controlled turns and pitch.
Material Roll Preparation
Suitable for fiber, tape, or continuous material winding where stable tension and repeatable roll shape are required.
Automated Winding Cells
Can be integrated with feeders, tension devices, cutting units, conveyors, robot handling, inspection stations, and production data management.
